Length: 250 cm
Width: 25 cm
Height: 90 cm
Weight: Approx. 35 kg
Speed (Max.): 20 km/hr.
Range: Approx. 15-50 km depending on road and snow condition
Drag Force: Approx. 90 kgF
Inclination Range: 15-20% with 90 kg rider weight
No. of Battery: 1
No. of Motor: 1
Battery: 48V / 17.5 Ah Li-Ion battery
The Lizard battery is a battery you can mount on the bike’s frame 2 water bottle bolt mount. This is the thinnest battery case for suspension frames or small size frames. Check the bicycle frame down tube geometry then select. The battery can be locked to its support or un-lock and slide out to remove.
Li-Ion 48V 17.5Ah
Energy: 840Wh
Max Power: 1200W
Standard recharge time 8 hours
Battery Pack Specification:
PVC covered 18650Cells and BMS pack
SANYO GA 3500
Charging Model CC/CV
Charge Temperature 0-45°C
Discharge Temperature -20-55°C
Charger Voltage: 54.6V
4.5kg
Dimensions 370 x 110 x 90 mm
Motor: 750W Rated (1200W Max.) Geared Motor
1200W using 48V 25A controller, hub motor, small size with simple structure, lightweight and long life, superpower, high efficiency, beautiful, high-speed motor with gear, the drive is very free and fluent, the best choice for Li-ion battery on an e-bike for the rough road, higher weights and higher grade-ability.
Motor Type: DC Brushless Geared Hub Motor
Motor Power: 750W /1200W
Voltage: 48V
Max Torque: 120Nm @25A
Efficiency ≥80%
Sun-planetary reduction gears with regenerative braking option
36 Spokes
Flange for disc brake
Waterproof connector
Axle=135mm, Diameter=177mm.
Weight=4kg
The phase angle of 120 degree
Manufacturer: MXUS
Waterproof and protection grade: IP54
Noise level 55dB
CE, EN15194 certifications
Material:
Wheel, A356 Aluminum
Magnet, 38SH
Wire(winding), QZ-3/155
Iron core, DW470
Bearing, C&U
Display Computer
LCD3 meter provides you with a variety of functions such as vehicle controls and vehicle status digitized displays to meet the trip demands.
Pedal Assist System (PAS) optimized to simulate the torque sensor. This computing system provides Speed limit PAS or Torque limit PAS levels from 0 to 5.
Trip time display (with displays of a single trip time (TM) and total trip time (TTM));
Trip speed display (with displays of real-time speed (Km/H or MPH) and a single maximum speed (MXS) and a single average speed (AVS));
Trip distance display (with displays of a single trip distance (DST) and total trip distance (ODO));
Display of turned on the handlebar;
Display of power-assist startup;
Power assistant ratio (or handlebar) gear (ASSIST) switch;
6Km/H power assistant push function;
Cruise function (CRUISE);
Battery capacity indicator;
Real-time battery voltage (VOL) display;
Motor power and temperature (MOTOR) display;
Brake display;
Turn on backlighting and lights ;
Environment temperature display;
Data clearing;
Fault code display;
User parameter setting
5′ large screen
Rubber clamp spacer is provided for 3 handlebars bore sizes: 22.5mm, 25.4mm, 31.5mm
Easy key button, easy control,
Waterproof housing with good appearance
Motor Controller:
Brushless Motor Controller
Voltage: 48V
Min Voltage: 42+-0.5V
Max Current: 25+-1A
Speed Set: 1-4.2V
Angle: 120
Brake Input: Low-Level
Thumb Throttle:
Haul effect sensor, Analogue linear increasing torque
Pedal Assist Sensor
2 pieces 12 Magnet easy assemble Pedal Assist Sensor,
Just stick the sensor, no need to disassemble the crank.
this sensor is compatible with optimized PAS controlling systems and provides the best pedal assist performance, rapid response and torque sensor simulation.
Brake Cut-Off Magnetic Switches
Just stick the magnet sensors, no need to disassemble the brake levers.
it cuts-off the motor when you brake
Electric regenerative braking
Rainproof Controller and Tool Bag
